TS9 female Jack to CRC9 male plug straight connector with 20cm 8″ RF RG316 RG-316 RF Coaxial Pigtail High Quality Low Loss cable

Search E.g. : Input SMA N Cable and click Search button , then you can find out All items for ” SMA and N Cable ” .

Parts name: TS9 female jack to CRC9 male plug connector 8inch 20cm RG316 RF Coaxial Pigtail cable
production capacity: 1000pcs per day ( If large quantity purchase, pls. contact us to )

Specifications:

Fresh and High Quality and Low Loss !

* Connector A : TS9 female jack ( center is hole female pin)
* Connector B : CRC9 male plug ( center is plug male pin)
* Cable Length: 8inch ( about 20cm )
* Cable — type: RG316 RF Coaxial Pigtail cable
* Plating: gold plated contacts, nickel-plated, real teflon insulator
* Mounting: machined brass construction crimped & soldered cable mount
* Salt spray test: >=24 hour -48 hours, enhanced corrosion resistance
* Operating frequency: with highest quality, >= 2.4Ghz 3Ghz 5Ghz 8Ghz 15Ghz…
* Technical characteristics
* Temp. range: -65 ~ +165 (PE cable -55 ~ +85)
* Impedance: 50 ohm

Package included:

* 1 x TS9 female jack connector to CRC9 male plug RG316 RF Coaxial Low Loss cable 8inch 20cm

Important Tips:

* If you want this item in 50cm length instead 20cm length, you could place the order of this 20cm cable together with the item “30cm Extension-cable” at the same time.
* Besides, please leave a message for the order about the correct final length (50cm) or Contact us, then we will make the “Connector A to B in 50cm long cable” for you and ship it out ASAP.

* All items for different Extension cable in different length as below:
