8CH 960P/8CH 1080P/ Mobile HDD
• P2P cloud service, including cloud connecting, cloud monitoring, cloud transmitting to access IPC and NVR at any time and any place
• Support Onvif protocol, support High profile S, High profile G, compatible with different IP camera that based on Onvif, RTSP standard
• Support megapixel HD network video preview, storage and playback;
• Support search, playback and backup by event;
• Support all channel image display on one screen at same time, support 4 channels’ image display by mainstream, and 4 channels playback;
• Support monitor PTZ on preview mode
• Offer CMS for free
IMP-MINI-NVR8 |
||
Operating System |
Embedded LINUX operating system |
|
Image Code Control |
Image code quality adjustable, variable bitstream and constant bitstream optional |
|
Dual Stream |
Each channel can set main stream and sub stream |
|
Video Standard |
1080P(1920×1080)30fps/960P/(1280×960)/720P(1280×720)30fps |
|
Monitoring Image Quality |
1080P(1920×1080) / 960P/(1280×960)/720P(1280×720) |
|
Image Motion Detection |
Each screen can set mutiple detection areas and set 6-level sensitivity(IPC Support) |
|
Recording Playback Quality |
4ch playback in8ch 720/960P mode; 1ch 1080P playback in 8ch 1080P mode |
|
Region Cover |
Every channel can set 4 cover regions(IPC Support) |
|
Recording Mode |
Support manual , auto, dynamic detection, alarm trigger record mode(Partly needs IPC Support) |
|
Backup Way |
Support U disk, USB mobile HDD, USB DVD-RW, network storage and backup |
|
Operation Way |
Mouse |
|
Local Login |
User name and password |
|
Recording Storage |
Local HDD, network |
|
External Ports |
Video Input |
8×(1280*720)+sub[640*360]+1Ref.+4Play 8CH 1.0MP IP Camera |
8×(1280*960)+sub[640*480]+4Ref.+1Play 8CH 1.3MP IP Camera |
||
8×(1280*960)+sub[720*576]+2Ref.+1Play 8CH 1.3MP IP Camera |
||
8×(1920*1080)+sub[720*576]+1Ref.+1Play 8CH 2.0MP IP Camera |
||
Audio Input |
8ch network audio input |
|
Video Output |
1ch VGA+1ch HDMI |
|
Network Port |
1 RJ45,10M/100M self-adaptive LAN port |
|
USB Port |
2 USB 2.0 ports |
|
Wireless Port |
NO |
|
HDD |
Mobile HDD/E-SATA/USB Disk |
|
Mobile Surveillance |
Support( iPhone, Windows Mobile, BlackBerry, Symbian,Android) smart phone |
|
Power Supply |
5V2A |
|
Power Consumption |
≤10W(without HDD) |
|
Working Temperature |
-10C~+55C |
|
Working Humidity |
10%-90% |
|
Dimension |
Equipment:88mm×88mm×32mm,Packing:185.5mm×115.5mm×36mm |
|
Weight(without HDD) |
N.W.: 105g; With packing:250 |
|
Outside Carton |
30 pcs/carton. 365mm×350mm×188mm; Weight: 8kg |
|
Installation Way |
Desktop Installation |
PS:If don’t receive the message or comment about the color, will ship randomly
